| Specification | Details |
|---|
| Size Range | 2.1/2″ to 48″ (65MM to 1200MM) |
| Temperature Range | Up to 220°C |
| Pressure Class | PN 16 |
| Shutoff Rating | Tight Shut Off |
| Body Style | Wafer Type |
| Flange Drilling | 150#, 300#, AWWA, Series-A, Series-B, EN 1092-1, EN 1092-2 |
| Body Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY-20 |
| Stem Materials | SS 304, SS 316, SS 410, 17-4 PH, SS 316L |
| Seat Materials | EPDM, EPDM-H, VITON |
| Disc Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY-20 |
| Design Standard | BSEN 593, ISI 3095, API 609, AWWA C-504 |
| Testing Standard | API 598, BSEN-12266-1, AWWA C-504 |
| Face-To-Face Standard | API-609, BSEN 558, AWWA C-504 / 516 |
1 – Triple Offset Design: Enhances sealing performance and extends valve life by reducing friction and wear.
2 – Precision Engineering: Provides a tight, reliable shutoff, even under high pressure and temperature conditions.
3 – Wafer Type Construction: Simplifies installation between flanges, offering space-saving and flexibility.
4 – Durable Materials: Built to withstand harsh industrial environments and ensure long-term reliability.
5 – Versatile Application: Suitable for a wide range of fluids, including water, chemicals, and gases.
6 – Low Maintenance: Designed for minimal upkeep and dependable operation over time.
1 – Triple Offset Design: Enhances sealing performance and extends valve life by reducing friction and wear.
2 – Precision Engineering: Provides a tight, reliable shutoff, even under high pressure and temperature conditions.
3 – Wafer Type Construction: Simplifies installation between flanges, offering space-saving and flexibility.
4 – Durable Materials: Built to withstand harsh industrial environments and ensure long-term reliability.
5 – Versatile Application: Suitable for a wide range of fluids, including water, chemicals, and gases.
6 – Low Maintenance: Designed for minimal upkeep and dependable operation over time.
