Segmented Type Flush Bottom Valve

Specification	Details
Model	SBB / SBR
Operation	– Pneumatic (D/A & S/A actuator) – Motorized
Sizes	4’’ to 14’’ (100mm to 350mm)
Working Pressure	Up to 10 kg/cm²
Temperature	Up to 250°C
Leakage	Class VI
Material of Construction	SS304 / SS316 / SS316L (Special alloy on request)
Seals	PTFE / CFT / GFT
Media	AIR / WATER / OIL / POWDER / VACUUM
Flange Connection	– ASME B16.5 150# – ASME B16.5 300#

Description

Talk to our team for orders, pricing, and quotations, fast response guaranteed.

Mark & Aira Valves

At Mark & Aira Valves, we believe that exceptional quality begins with rigorous quality control processes. Our commitment to excellence is reflected in our comprehensive inspections and evaluations conducted at every stage of production.
