| Specification | Details |
|---|
| Design & Manufacturer | ASME B16.34 / BS EN ISO 17292 |
| Threaded Fitting | ASME B1.20 |
| Inspection & Testing | API 598 / ISO-5208 / BS EN 12266-1 |
| Leakage Class | Class VI (ISO 5208) |
| Size Range | 1/2″ to 2″ BSP / NPT Thread |
| Temperature Range | -50°C to 300°C for Soft Seated Valves. Contact Works for Special Requirements (Up to -50°C to 420°C) |
| Pressure Class | 150# |
| Media | Air / Water / Oil / Gas |
| Body Material | Cast Iron (CI), Ductile Iron (DI), S.G Iron (SGI), WCB, CF8, CF8M, CF3M, SS 304L, Duplex, Hast Alloy, Monel |
| Ball Material | CF8, CF8M, WCB + ENP, Hast Alloy, Duplex, Monel, CF3M |
| Ball Type | Solid |
| Stem Material | AISI 410, SS 304, SS 316, SS 304L, SS 316L, Duplex 2205, Duplex 2507, Monel |
| Seat Material | PTFE, RPTFE, CFT, GFT, Modified PTFE, AIRA-250, Nylon, Devlon, PEEK, D-Plastic |
| Certification | POD |
1- Fully Compliant To ASME B16.34 & API 608.
2- ISO 5211 Mounting Pad Bolt Pattern.
3- Blow Outproof Steam Design.
4- Anti Static Grounded Ball & Stem.
5- Slot Vented Ball For Thermal Expansion.
6- Also Manufacture In Special Grade MOC Like Supen Duplex, Hast Alloy Etc.
7- Ball Seal: RPTFE, TFM, PEEK.
