| Specification | Details |
|---|---|
| Design & Manufacturer | API 600 / BS 1873 |
| Valve Face To Face Dimension | DIN 3202 |
| Inspection & Testing | API 598 / BS EN 12266 PART – I |
| Leakage Class | Class VI |
| End Connection | Flanged End |
| Valve Rating | Flanged 150# |
| Spark Test | 15 kV DC to 40 kV DC |
| Certification | Design CE Approved, SIL3 Approved, IBR Approved |
| Shut Off Rating | VI Class |
| Stem Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
| Size Range | 1/2″ to 8″ (15 MM to 200 MM) |
| Temperature Range | -50°C to 300°C for Soft Seated Valves. Contact Works for Special Requirement |
| Pressure Class | PN 6 |
| Media | Chemical |
| Body Material | CAST IRON (CI), DUCTILE IRON (DI), S.G IRON (SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL |
| Bonnet Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
| Flange Drilling | ASME B 16.5 Class 150# |
| Face To Face | ASME B 16.10 |
| Fugitive Emissions | Yes |
| Disc Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
1 – UPPER STEM BUSHING: An upper stem bushing, retainer by a stainless steel ring, is provide to absorb actuator side thrusts and is acetal as standard or PTFE as an option.
2 – UPPPER STEM SEAL: Keeps environmental contaminants from entering the stem bore.
3 – BEARINGS: PTFE impregnated steel bearing provided for the precision alignment of the upper and lower stem.
4 – PRIMARY SEAL: The primary seal is achieved by an interference fit between the extra wide disc hubs and contoured seat.
5- SEAT DESIGN: The unique seat geometry lowers seating unseating toque while reducing wear on the contacting parts
1 – UPPER STEM BUSHING: An upper stem bushing, retainer by a stainless steel ring, is provide to absorb actuator side thrusts and is acetal as standard or PTFE as an option.
2 – UPPPER STEM SEAL: Keeps environmental contaminants from entering the stem bore.
3 – BEARINGS: PTFE impregnated steel bearing provided for the precision alignment of the upper and lower stem.
4 – PRIMARY SEAL: The primary seal is achieved by an interference fit between the extra wide disc hubs and contoured seat.
5- SEAT DESIGN: The unique seat geometry lowers seating unseating toque while reducing wear on the contacting parts
