| Specification | Details |
|---|
| Design & Manufacturer | API 609 Category A / IS : 13095 / BSEN 593 / AWWA C 504 |
| Valve Face To Face | ASME B 16.10 (Other F-To-F Available on Request) |
| Inspection & Testing | API 598 / BSEN 12266-1 / AWWA C 504 |
| Seat Leakage Class | 5% Leakage of Main Flow (Class 1 Available on Request) |
| End Connection | Double Flange Type |
| Top Flange Drilling | ASME B16.5 / 16.47 Series A Class 150 / AWWA C 504 |
| Disc Material | SS 304, SS 316, M.S. Fabricated |
| Certification | Design CE Approved, SIL3 Approved, POD |
| Size Range | 8″ to 80″ (200 MM to 2000 MM) |
| Temperature Range | -50°C to 300°C (For Soft Seated Valves, Contact Works for Special Requirements) |
| Pressure Class | Only Body PN 6 (Maximum) |
| Media | Air, Water, Oil, Gas, Light Chemical, Steam |
| Valve Pressure | 5 to 10 Kg/Cm² |
| Pneumatic Pressure | 5 to 10 Bars |
| Leakage Class | 4 to 5% Leakage of Full Flow |
| Body Material | Cast Iron, S.G. Iron, M.S. Fabricated, SS 304 |
| Seat Material | SS 304, SS 316, Metal to Metal |
