| Specification | Standard |
|---|---|
| Size Range | ARA-5412 To ARA-400 |
| Temperature Range | -20°C To 90°C |
| Working Pressure | 4 To 8 Bar |
| Method Of Transmission | Rack And Pinion Type |
| Actuation | Double Acting |
| Body | Extruded Aluminium Hard Anodized |
| Caps And Rack | Aluminium Pressure Die Cast |
| Pinion | EN 8 |
| Seals | Buna – N / Viton |
| Air Pressure | Normal Air Supply Pressure: 4KG/CM², Air Supply Pressure: 8KG/CM² Max |
| Actuator Design | ISO 5211 (Actuator Can Be Quickly And Easily Mounted) |
| Rotation | 90° Rotation |
| Torque | 0 To 8546 NM |
| Mounting PCD | ISO 5211 Mounting Standard |
| Body Material | Aluminium – Extruded |
| Piston Material | Aluminium |
| Applications | Operating For Valve |
