| Specification | Standard |
|---|---|
| Size Range | ARA-328 To ARA-1108 |
| Temperature Range | -20°C To 90°C |
| Working Pressure | 4 To 8 Bar |
| Method Of Transmission | Rack And Pinion Type |
| Actuation | Double Acting |
| Body | Extruded Aluminium Hard Anodized |
| Caps And Rack | Aluminium Pressure Die Cast |
| Pinion | EN 8 |
| Seals | Nitrile |
| Air Pressure | Normal Air Supply Pressure: 3KG/CM², Air Supply Pressure: 8KG/CM² Max |
| Actuator Design | ISO 5211 (Actuator Can Be Quickly And Easily Mounted) |
| Rotation | 180° Rotation |
| Torque | 0 To 140 NM |
| Mounting PCD | As Per ISO 5211 Mounting Standard |
| Piston Material | Aluminium |
| Application | Operating For Valve |
1 – Suitable typically for 3 way vales, requiring ON – OFF operation. It is available in both double acting versions.
2 – The 180° actuator can provide center off for the 3 way ball valve, bottom entry by choosing the option,of 3 position.
3 – The end stop adjustment is provided for opening and closing direction as a standard.
4 – Actuator mounting is as per ISO 5211 & Accessories to Namur Solenoid Valve.
1 – Suitable typically for 3 way vales, requiring ON – OFF operation. It is available in both double acting versions.
2 – The 180° actuator can provide center off for the 3 way ball valve, bottom entry by choosing the option,of 3 position.
3 – The end stop adjustment is provided for opening and closing direction as a standard.
4 – Actuator mounting is as per ISO 5211 & Accessories to Namur Solenoid Valve.
