| Specification | Details |
|---|
| Design & Manufacturer | ASME B16.34 / BS EN ISO 17292 |
| Valve Face-to-Face Dimension | As Per Manufacturing Standard |
| Inspection & Testing | API 598 / ISO-5208 / BS EN 12266-1 |
| End Connection | ASME B16.5 Class 150 for Screw End |
| Size Range | 1/2″ to 3″ Screw End 150# |
| Temperature Range | -50°C to 300°C for Soft Seated Valves. Special requirements available upon request |
| Pressure Class | 150# |
| Media | Air / Water / Oil / Gas |
| Body Material | WCB, CF3, CF8, CF8M, CF3M, SS 304L, Duplex, Hast Alloy, Monel, Ductile Iron, S.G Iron |
| Ball Material | CF3, CF3M, CF8, CF8M, WCB + ENP, Hast Alloy, Duplex |
| Ball Type | Hollow / Solid |
| Stem Material | CF3, CF3M, CF8, CF8M, 410, Duplex 2205, Duplex 2507, Monel, 17-4 PH |
| Seat Material | PTFE, RPTFE, Modified PTFE, AIRA-250 |
| Certification | Design CE Approved, Fire Safe, POD |
1 – High Performance Ball Valve.
2 – Antistatic Design.
3 – ISO 5211 Mounting Pad Available.
4 – Low Pressure Drop.
5 – Longer Life.
6 – Thousand OF Cycle.
7 – V-Type Cheuron Gland Packing, Which Leads To Zero Leak After.
8 – mixing and diverting.
