Durable C Way Multi Port Flanged End Ball Valve Supplier UAE

Specification & Standard

Here’s the comprehensive specification for your valve based on the latest input:

Parameter	Details
Design & Manufacturer	ASME B16.34 / BS EN ISO 17292
Valve Face to Face Dimension	As per Manufacturing
Inspection & Testing	API 598 / ISO 5208 / BS EN 12266-1
Flange Standard Conformity	ASME B16.5 Class 150
End Connection	ASME B16.5 Class 150 for Flange End
Size Range	1/2″ to 8″ Flange End 150#
Temperature Range	-50°C to 300°C for Soft Seated Valves (Contact for Special Requirement)
Pressure Class	150#
Media	Air, Water, Oil, Gas
Body Material	WCB, CF3, CF8, CF8M, CF3M, SS 304L, Duplex, Hast Alloy, Monel, Ductile Iron, S.G Iron
Ball Material	CF3, CF3M, CF8, CF8M, WCB + ENP, Hast Alloy, Duplex
Ball Type	Hollow / Solid
Stem Material	CF3, CF3M, CF8, CF8M, 410, Duplex 2205, Duplex 2507, Monel, 17-4 PH
Seat Material	PTFE, RPTFE, Modified PTFE, AIRA-250
Flange Drilling	ASME B16.5 Class 150#
Certification	Design CE Approved, Fire Safe, POD
