| Specification | Details |
|---|---|
| Size Range | 15MM to 100MM |
| Temperature Range | Up to 450°C Max |
| Shutoff Rating | Tight Shut Off Leakage Class – 6 |
| Body Style | Metal To Metal |
| Flange Drilling | 150#, 300#, 600# |
| Certification | IBR Approved |
| Body Materials | WCB / CF8 / CF8M |
| Stem Materials | S.S – 304 / S.S – 316 |
| Seat Materials | PTFE / CFT / GFT |
| Plug Materials | S.S – 304 / S.S – 316 |
| Design Standard | BS 6697 |
| End Connection | ASME B16.5 |
| Testing Standard | FCI 70 – 2 |
| Face to Face | ISA – 75.03, IEC 534 – 3 |
| Leakage | Class IV |
| Applications | Steam / Gas / Water |
1 – Available in 2/2 and 3/2 way options.
2 – Pneumatic Cylinder Operated.
3 – Provides reliable control for directing airflow in pneumatic systems.
4 – Built for long-term use with robust construction.
5 – Allows precise control of the flow of compressed air, ideal for automation and machinery applications.
6 – Compact and efficient design for easy integration into various systems.
7 – Typically constructed from high-quality metals or durable polymers for enhanced performance.
1 – Available in 2/2 and 3/2 way options.
2 – Pneumatic Cylinder Operated.
3 – Provides reliable control for directing airflow in pneumatic systems.
4 – Built for long-term use with robust construction.
5 – Allows precise control of the flow of compressed air, ideal for automation and machinery applications.
6 – Compact and efficient design for easy integration into various systems.
7 – Typically constructed from high-quality metals or durable polymers for enhanced performance.
