| Parameter | Details |
|---|---|
| Size Range | 1/2″ to 1.1/2″ Screwed |
| Temperature Range | Rated for 80°C max (For high temperature up to 125°C, Viton diaphragm with Viton seat can be provided) |
| Pressure Class | 0.6 to 8.5 Bar max |
| Media | Dust Collector Application, Cartridge Filter, Envelope Filter |
| Body Material | Aluminium |
| Seat Material | NBR |
| Certification | CE |
1 – Designed to handle a specific range of pressures, suitable for various industrial applications. The exact range will depend on the specific model.
2 – Features threaded (screwed) connections for easy installation and integration into existing piping systems
3 – Designed for low maintenance with easy access to parts for cleaning or replacement if necessary.
4 – May include features to ensure safe operation, such as over-temperature protection or protection against electrical faults.
1 – Designed to handle a specific range of pressures, suitable for various industrial applications. The exact range will depend on the specific model.
2 – Features threaded (screwed) connections for easy installation and integration into existing piping systems
3 – Designed for low maintenance with easy access to parts for cleaning or replacement if necessary.
4 – May include features to ensure safe operation, such as over-temperature protection or protection against electrical faults.
